Poliuretano Co., srl di Yongjia.
 |
| Luogo di origine: | Jiangsu, Cina |
| Marca: | Yongjia |
| Certificazione: | CE |
| Numero di modello: | macchina della schiuma di pressione bassa |
| Quantità di ordine minimo: | 1 insieme/insieme |
|---|---|
| Prezzo: | negotiable |
| Imballaggi particolari: | scatola di legno degna del mare per la macchina a iniezione nuovissima della schiuma di poliuretano |
| Tempi di consegna: | 45-60 giorni |
| Termini di pagamento: | L/C, D/A, D/P, T/T, Western Union, |
| Capacità di alimentazione: | 500 insieme/insiemi per Macchina a iniezione della schiuma di poliuretano di pressione bassa di me |
| Tipo di prodotto: | Rete della schiuma | Dimensione (l*w*h): | 4100 (L)*1250 (W)*2300 (H) millimetro |
|---|---|---|---|
| Tipo a macchina: | macchina a iniezione | circostanza: | Nuovo |
| Tensione: | 380V | Potere (chilowatt): | 168kW |
| Peso (chilogrammi): | 1200 chilogrammi | Garanzia: | 1 anno |
| Servizio di assistenza al cliente fornito: | Video supporto tecnico, pezzi di ricambio liberi, installazione del campo, incaricante e preparantes | Punti di vendita chiave: | Automatico |
| Dopo servizio della garanzia: | Video supporto tecnico, supporto online, servizio dei pezzi di ricambio, di manutenzione sul campo e | Industrie applicabili: | Fabbrica |
| Nome: | estintore a schiuma dell'iniezione | Filtro: | filtro autopulente |
| Alimentazione materiale: | sistema d'alimentazione automatico | sistema di controllo: | SpA |
| pompa dosatrice: | misurare preciso | tipo della schiuma: | schiuma flessibile |
| Volume del carro armato: | 250L | Potere: | 380V a cinque vie trifase |
| Evidenziare: | Macchina a iniezione della schiuma dell'unità di elaborazione di pressione bassa 50HZ,macchina a iniezione della schiuma dell'unità di elaborazione di pressione bassa 250L,Macchina a iniezione della schiuma di poliuretano 50HZ |
||
| No. | Item | Technical parameter |
| 1 | Foam application | Flexible Foam Mats |
| 2 | Raw material viscosity(22℃) |
POL ～3000CPS ISO ～1000MPas |
| 3 | Injection flow rate | 54-216g/s |
| 4 | Mixing ratio range | 100:28～48 |
| 5 | Mixing head | 2800-5000rpm, forced dynamic mixing |
| 6 | Tank Volume | 120L |
| 7 | Input power | Three-phase five-wire 380V 50HZ |
| 8 | Rated power | About 11KW |
| 9 | Swing arm | Rotatable 90°swing arm, 2.3m (length customizable) |
| 10 | Volume | 4100(L)*1300(W)*2300(H)mm, swing arm included |
| 11 | Color( customizable) | Cream-colored/orange/deep sea blue |
| 12 | Weight | About 1000Kg |
This is the storage tank A and B tank of the polyurethane high pressure machine. Polyurethane and Isocyanate raw materials are separately installed.
Material of the tank: SS304
Size of feeding flange: φ150
Capacity: 250L
Quantity: 2
The mixing head adopts floating mechanical seals, and its high shear mixing screw head, which can mix two materials (Polyurethane and Isocyanate) with better performance.The raw materials are stirred at high speed in the mixing chamber by stirring blades to achieve a mixing effect, so that the liquid is uniformly sprayed to form a desired product.
1. Fully controlled by SCM (Single Chip Microcomputer).
2. Using PCL touch screen computer. Temperature,pressure, revolving speed display system.
3. Alarm function with acoustic warning.
We have our own technical team of chemical engineers and process engineers, all of whom have more than 20 years of experience in PU industry. We can independently develop raw material formulas like polyurethane rigid foam, PU flexible foam, polyurethane integral skin foam and polyurea that meet all customer' s requirements.
Polyurethane low pressure machine can be used to manufacture floor mat.
Yongjia Polyurethane Co., Ltd. is a professional machinery manufacturer in PU industry combined with design, development, production. Founded in 2013, the construction area of over 10,000 square meters, is the China forefront polyurethane technology company. At present our company's products range covers:high pressure pouring machine, low pressure foaming machine, PU spraying foam machine, PU elastomer casting machine, also we customize to make production line according to clients requirement,like in flexible foam system we make the lines: PU shoe /sole/insole production line(Egypt),anti-fatigue mat production line(India),memory pillow production line(Iran),Albania,elastic ball production line(Mexico),car seat and cushion production line(Morocco),PU slow rebound ear plugs line(India);rigid foam system we make the line:PU decorative molding crown cornice line(Saudi Arab), float trowel making line(Saudi Arab, Pakistan), cold storage panel production line(Uzbekistan),sandwich panel production line(Iraq).Elastomer line:forklift wheel casting line(lran);coal sieve screen select line(Russia).
We have professional team of mechanical engineer, chemical engineer, process engineer, etc, all of them have more than 10 years experience in PU foam filed. Also, we have special sales team, they are young but hard-working and experienced. We can meet any your requirements of the PU foam product, pu mold and PU foam machines.
1. Professional and patient consulting service to help you find the suitable solution.
2. Further negotiation about the technical details, machine configuration, price basis, payment term and delivery time.
3. Powerful control of the machine production schedule and quality, and keep you posted about details in time.
4. Free training in our plant during machine inspection. Or photos and video of the machine and package for your confirmation before shipment.
5. Quick and safe shipment as per your requirement including the booking ,container loading, and shipping documents.
6. For technical support, we can help you online by email and phone, also we can send technicians to your site if necessary.
7. For the spare parts, we will supply the parts for free during one year guarantee period, also the parts supplying at original cost after that .
8. We give an accessory box for free.
9. We offer development solutions for raw material formulations.
10. If you need to visit the factory, we will arrange for personnel to pick up the airport.
